Working Scope of Zigzag Feeding Metal Round Plate

• The thickness of product: 0.3-3.2mm/0.5-6.0mm.
• Material compatibility: It suits for the material as steel, copper, aluminum, special alloy, thermometal and so on.

The Feature of Zigzag Feeding

• High output: It can finish many times shift. It can save 7% material in every move, basis on the calculation of the 60° corner. It will change the corner distribution according to the width of material that can increase the material utilization.
• High efficiency: The feeding speed can reach 60times/min.
• High-precision: In the process of continuous punch, it can set the min. distance between both sides within 0.5mm; the error of every move can make sure within ±0.08mm.
• Cover the space is little: The energy consumption is low.
• Automated material handling: The product will drop out on the conveyor after the punched, and then will send to the material platform by the conveyor.
• Complete automation control, can save labor resource: When the production line working, it just need one staff to operate the electric box. Input the operational program on the manual panel, the machines can complete automatic produce.
